SPECIFICATIONS

Application: Residential / General-Purpose

Backlight/Indication: Yes

Brand Name: Wallpad

Certification: CE

Extension Cable Length: None

Features: With USB Ports

Grounding: Standard Grounding

Hign-concerned Chemical: None

Installation Type: Wall Embedded

Is Smart Device: No

Material: Plastic,Fire Retardant PC

Model Number: S6 DIY

Module Color: Black

Module Size: 52*52mm

Number of slots: 3 or more

Origin: Mainland China

Panel Material: Acrylic

Panel Size 1: 86*86mm

Panel Size 2: 172*86mm

Panel Size 3: 258*86mm

Panel Size 4: 344*86mm

Panel Size 5: 430*86mm

Protection class: IP 20

Rated Current: 16A

Rated Power: 4000W

Rated Voltage: 110-250V

Shape: SQUARE

Socket Type: Combined

Standard: DIY Module

Wallpad Black DIY Module Acrylic Panel With Gold Border Wall Power Socket Electrical Outlet S6 Function Key Free Combination

►Main Feature

Black Acrylic Panel

The frame made of acrylic, For frame will come with acrylic panel+mid steel frame.

EU UK MF Socket

EU UK MF Socket meet many standard of plug

Socket with USB

USB: 5V 2100MA. There is LED indicator on it, When the USB is working the LED indicator will turn on.

2 USB Fast Charge Port

5V 3100mA  36W. Support QC2.0, QC3.0,FCP,AFC,BC1.2 fast charge protocol.  Fast charge will work for device which support fast charge function

WIFI AP Router

300M Wifi router, USB 5V 1000MA

USB3.0 HDMI

HDMI And USB3.0 only for DATA transmission. They should connect the HDMI and USB3.0 wires on the back of it. Note: USB3.0 not used for charge

►Note

1. The steel panel only come with frame, it will not come with the module

2.  Round box is not fit for our product

►Specification

Panel Material: Black acrylic
Panel Size 1: 86*86mm
Panel Size 2: 172*86mm
Panel Size 3: 258*86mm
Panel Size 4: 344*86mm
Panel Size 5: 430*86mm
Module Size: 52*52mm
Mounting Hole Distance: 60mm
Center Distance: 25mm
Rated Voltage:110-250V
Color:Black
Certification:CE

►Packing List

Frame:

1 Pcs of acrylic panel

1 Pcs of mid steel frame

2-10 Pcs of screws

(Screw number according to the multiple frame: single frame use 2 pcs, double frame use 4 pcs, 5 frame use 10pcs of screws)

Module:

1 Pcs of module

►RELIABLE AFTER-SALES SERVICE

Our friendly and reliable after-sales service team can provide the most professional solutions for any of your problems. Please rest assured for shopping.

All orders will be shipped out within 2~3 working days, except order placed in Chinese holidays.

DIY Black Acrylic Gold Border

Free Combination

Full Range

Over 40types of switch and socket

How to Install

Steel frame will come with plastic panel

Horizontal and Vertical

Multiple frame can be installed horizontal and vertical

Installation Size

Center distance: 25mm

Installation Box

1 Frame use 1pcs of box,2 Frame use 2pcs of box...5 Frame use 5pcs of box
